- Heavy duty tapered roller bearings with steel cage for radial, thrust and combined loading
- Race-mounted felt-lined flinger seal
- Double-collar interlock with 120° spacing setscrew lock, diamond faceted setscrews
- Powder coat epoxy 2-bolt split cast iron housing
ERPB 208-2
Sealmaster Mounted Cast Iron Two Bolt Pillow Block Tapered Roller – 52100 Bearing Steel – Double Collar Mount Lock – ERPB 208-2
$1,698.68
Out of stock
Out of stock
| Housing Material: | Cast Iron | Housing Base: | Solid |
|---|---|---|---|
| Rolling Element: | Tapered Roller | Expansion: | Yes |
| Insert Material: | 52100 Bearing Steel | Seal Type: | Felt Labyrinth Seal |
| Housing Type: | Pillow Block, Two Bolt | Measure Units: | Inch |
| Housing Construction: | Split Two Piece | Radial Dynamic Load Capacity (lb): | 9, 030 lb |
| Locking Type: | Double Collar Mount | Misalignment: | ±3.0° Misalignment - Static Only |
| Bore Shape: | Straight | Speed (Max): | 2000 |
| Internal Clearance: | Standard | Housing Color: | Gray |
| End Cap: | No | Misalignment Type: | Static Only |
| Bearing Insert Coating: | Uncoated | Replaceable Insert: | Yes |
| Retainer Material: | Steel | Platform: | RPB Series |
| Outer Ring Land Profile: | Standard | Series: | ERPB |
| Grease Fitting Thread Size: | 1/8 NPT | Ability to Relubricate: | Yes |
| Lubrication Type: | Lithium, EP, NLGI#2 | Maximum Operating Temperature (F): | 220 °F |
| Duty/Series: | Standard | Housing Style: | Pillow Block |
| Inner Race Heat Treat Method: | Case Carburized Inner Ring | Insert Number: | ERCI-208 |
| UPC: | 662288000000 | Weight: | 23.00 LB |
| Packaged Length: | 10.5 Inches | Packaged Width: | 5.88 Inches |
| Packaged Height: | 4.13 Inches | HTC: | 8483.20.8080 |
| Country of Origin: | United States of America |
