- Stud type cam follower
- Crowned outside diameter
- Needle rolling elements
- Slot hole
- LUBRI-DISC® seal
CCFH 7/8 S
McGill Heavy Stud CAMROL® Crowned Inch Cam Follower – Stud Mount Roller – Screwdriver Slot – Sealed – CCFH 7/8 S
$46.62
Out of stock
Out of stock
| Limiting Speed: | 5 | Rolling Element: | Needle Roller - Full Complement |
|---|---|---|---|
| Series: | Inch CAMROL® | Hex/Slot: | Screwdriver Slot |
| Sealing: | Sealed | Adjustment: | None |
| O.D. Configuration: | Crowned | Material: | Bearing Steel, Black Oxide Finish |
| Roller Shape: | Crowned | Tolerance Class: | P0 Equivalent |
| Platform: | CAMROL® | Stud Type: | Heavy Stud |
| Dynamic Load Rating (lb): | 1, 660 lb | Static Load Rating: | 2 |
| Ability to Relubricate: | No | Clamping Torque (in-lbf): | 250 lbs |
| UPC: | 726166032920 | Weight: | 0.11 LB |
| Packaged Length: | 1.75 Inches | Packaged Width: | 1 Inches |
| Packaged Height: | 1.75 Inches | HTC: | 8482.40.0000 |
| Country of Origin: | Mexico |
