- Stud type cam follower
- Crowned outside diameter
- Needle rolling elements
- Slot hole
- LUBRI-DISC® seal
CCF 1/2 S
McGill CAMROL® Crowned Inch Cam Follower – Stud Mount Roller – Screwdriver Slot – Sealed – CCF 1/2 S
$66.38
Out of stock
Out of stock
| Rolling Element: | Needle Roller - Full Complement | Sealing: | Sealed |
|---|---|---|---|
| Dynamic Radial Rating: | 680 | Hex/Slot: | Screwdriver Slot |
| Limiting Speed: | 12 | O.D. Configuration: | Crowned |
| Adjustment: | None | Series: | Inch CAMROL® |
| Material: | Bearing Steel, Black Oxide Finish | Roller Shape: | Crowned |
| Stud Type: | Standard Stud | Tolerance Class: | P0 Equivalent |
| Dynamic Load Rating (lb): | 680 lb | Platform: | CAMROL® |
| Static Load Rating: | 300 | Ability to Relubricate: | Yes |
| Clamping Torque (in-lbf): | 15 lbs | UPC: | 726166030148 |
| Weight: | 0.02 LB | Packaged Length: | 1.75 Inches |
| Packaged Width: | 1 Inches | Packaged Height: | 1.75 Inches |
| HTC: | 8482.40.0000 | Country of Origin: | Mexico |
