- Large Selection – MVP companion sheaves are offered in A/B, C, 5V & 8V belt sections and from 3-10 grooves giving Browning the largest selection of MVP Companion Sheaves in the industry.
- Statically Balanced – All MVP companion sheaves are statically balanced to assure smooth, vibration free performance.
- VP sheaves consist of a male with a threaded barrel, and a female with a threaded bore.
- The male section with threaded barrel has flat surfaces at 180 degree increments that allow a flat surface for the setscrew to mate with.
- When discs are moved toward each other, the belt rides higher in the groove and the pitch diameter of the sheave is larger which increases the driven speed.
- When discs are moved away from each other, the belt rides lower and the pitch diameter is smaller decreasing the driven speed.
5MVB50Q
Browning 5 Groove Cast Iron Bushed Bore Multiple Variable Pitch Sheave – 5MVB50Q
$1,894.02
Out of stock
Out of stock
| Bore (Min) (in): | 1 in | Material: | Cast Iron |
|---|---|---|---|
| Outside Diameter (in): | 5.35 in | Outside Length (in): | 6.578125 in |
| Pitch Diameter Range (A): | 4.8 | Product Type: | MVP Sheaves |
| Type of Bore: | Bushed | Number of Grooves: | 5 |
| Pitch Diameter Range (B): | 5.3 | Belt Section: | A, B |
| Bore (Max) (in): | 2.625 in | Face Width (in): | 5.5 in |
| Pulley Construction: | Type 5 | Bushing Used: | Q2 |
| UPC: | 662289265510 | Weight: | 15.57 LB |
| Packaged Length: | 7.10 Inches | Packaged Width: | 6.80 Inches |
| Packaged Height: | 6.30 Inches | HTC: | 8483.50.9040 |
| Country of Origin: | Mexico |
