- Raceway: Asymmetric, circular grooves
- Two direction axial load carrying
- Dimensions in accordance with ISO 355:2007
3307 C3
Rollway Angular Contact Ball Bearing – Double Row – Straight Bore – 3307 C3
$113.01
Out of stock
Out of stock
| Radial Clearance: | C3 | Contact Angle: | 30° |
|---|---|---|---|
| Series: | 3300 | Seal Type: | Unsealed |
| Bore Type: | Straight | Dynamic Load Rating (kN): | 51 kN |
| Misalignment: | No | Material: | 52100 Bearing Steel |
| Cage Material: | Steel | Rolling Element: | Ball |
| Number of Rows: | 2 | Static Load Rating (kN): | 30 kN |
| Full Complement/Caged: | Caged | Sealed: | None |
| Platform: | Double Row Angular Contact Ball Bearing | Speed (Max) Oil (rpm): | 7, 500 rpm |
| Duplexing: | No | Speed (Max) Grease (rpm): | 5, 600 rpm |
| Dynamic Load Rating (lb): | 11465 lb | UPC: | 637410095755 |
| Weight: | 1.65 LB | Packaged Length: | 3.15 Inches |
| Packaged Width: | 1.37 Inches | Packaged Height: | 3.15 Inches |
| Country of Origin: | China |
