- Raceway: Asymmetric, circular grooves
- Two direction axial load carrying
- Dimensions in accordance with ISO 355:2007
3209 C3
Rollway Angular Contact Ball Bearing – Double Row – Straight Bore – 3209 C3
$338.91
Availability: 2 in stock
Availability: 2 in stock
| Contact Angle: | 30° | Seal Type: | Unsealed |
|---|---|---|---|
| Radial Clearance: | C3 | Series: | 3200 |
| Bore Type: | Straight | Number of Rows: | 2 |
| Dynamic Load Rating (kN): | 49 kN | Cage Material: | Steel |
| Material: | 52100 Bearing Steel | Rolling Element: | Ball |
| Misalignment: | No | Static Load Rating (kN): | 32.5 kN |
| Platform: | Double Row Angular Contact Ball Bearing | Full Complement/Caged: | Caged |
| Speed (Max) Oil (rpm): | 6, 700 rpm | Speed (Max) Grease (rpm): | 5, 000 rpm |
| Sealed: | None | Duplexing: | No |
| Dynamic Load Rating (lb): | 11016 lb | UPC: | 637410095199 |
| Weight: | 1.57 LB | Packaged Length: | 3.35 Inches |
| Packaged Width: | 1.19 Inches | Packaged Height: | 3.35 Inches |
| Country of Origin: | China |
