- Raceway: Asymmetric, circular grooves
- Two direction axial load carrying
- Dimensions in accordance with ISO 355:2007
3208 C3
Rollway Angular Contact Ball Bearing – Double Row – Straight Bore – 3208 C3
$313.14
Out of stock
Out of stock
| Seal Type: | Unsealed | Radial Clearance: | C3 |
|---|---|---|---|
| Series: | 3200 | Contact Angle: | 30° |
| Bore Type: | Straight | Cage Material: | Steel |
| Material: | 52100 Bearing Steel | Static Load Rating (kN): | 31.5 kN |
| Misalignment: | No | Number of Rows: | 2 |
| Dynamic Load Rating (kN): | 48 kN | Rolling Element: | Ball |
| Speed (Max) Oil (rpm): | 7, 500 rpm | Speed (Max) Grease (rpm): | 5, 600 rpm |
| Sealed: | None | Full Complement/Caged: | Caged |
| Duplexing: | No | Platform: | Double Row Angular Contact Ball Bearing |
| Dynamic Load Rating (lb): | 10791 lb | UPC: | 637410095151 |
| Weight: | 1.33 LB | Packaged Length: | 3.15 Inches |
| Packaged Width: | 1.19 Inches | Packaged Height: | 3.15 Inches |
| Country of Origin: | China |
