- Double row ball bearing
- Outer ring raceway: Spherical
- Inner ring raceway: 1 linear surface
- Absorb shaft misalignments (max. 3 degrees depending of series number)
2309 C3
Rollway Radial Ball Bearing – Self-Aligning – Straight Bore – 2309 C3
$373.65
Out of stock
Out of stock
| Radial Clearance: | C3 | Angular Misalignment: | +/- 3 |
|---|---|---|---|
| Series: | 2300 | Cage Material: | Steel |
| Seal Type: | Unsealed | Rolling Element: | Ball |
| Dynamic Load Rating (kN): | 54.1 kN | Misalignment: | Yes |
| Material: | 52100 Bearing Steel | Bore Type: | Straight |
| Static Load Rating (kN): | 16.5 kN | Speed (Max) Grease (rpm): | 5, 600 rpm |
| Sealed: | None | Full Complement/Caged: | Caged |
| Speed (Max) Oil (rpm): | 6, 700 rpm | Duplexing: | No |
| Platform: | Self-Aligning Ball Bearings | Static Load Rating (lb): | 3, 709 lb |
| Dynamic Load Rating (lb): | 12, 162 lb | Mounting Method: | Shaft |
| UPC: | 637410094598 | Weight: | 2.72 LB |
| Packaged Length: | 3.94 Inches | Packaged Width: | 1.42 Inches |
| Packaged Height: | 3.94 Inches | Country of Origin: | China |
