- Constant Speed – No slip, no creep, minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
- Light Weight – High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
- Broad depth of product to choose from – Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
- Different Mounting to the shaft – Browning offers the Gearbelt Pulleys in various ways to mount to the shaft, Split Taper, QD Bushing styles, as well as, finished and minimum plain bore.
18XH300SK
Browning Steel Bushed Bore Gearbelt Pulley – 18XH300SK
$688.57
Out of stock
Out of stock
| Product Type: | Gearbelt Pulley | Width (mm): | 76.2 mm |
|---|---|---|---|
| Bore Range: | 1/2 to 2 5/8 | Number of teeth: | 18 |
| Bore Type: | Bushed Bore | Material: | Steel |
| Flange (in): | 5.5625 in | Width (in): | 3 in |
| Pitch Diameter (in): | 5.013 in | Outside Diameter (mm): | 124.5362 mm |
| Inside Diameter (in): | 3.125 in | Belt Section: | XH |
| Outside Diameter (in): | 4.903 in | Face Width: | 3.625 |
| Length Through Bore: | 1.75 | Hub Diameter (in): | 3.875 in |
| Pulley Construction: | Solid | Overall Length (in): | 4.685 in |
| Hub Projection: | 1.0625 | With Flanges: | With Flanges |
| Number of Hubs: | 1 | UPC: | 662289346134 |
| Weight: | 7.00 LB | Packaged Length: | 6.06 Inches |
| Packaged Width: | 6.06 Inches | Packaged Height: | 4 Inches |
| HTC: | 8483.50.9080 |
