- Double row ball bearing
- Outer ring raceway: Spherical
- Inner ring raceway: 1 linear surface
- Absorb shaft misalignments (max. 3 degrees depending of series number)
1213 C3
Rollway Radial Ball Bearing – Self-Aligning – Straight Bore – 1213 C3
$541.62
Out of stock
Out of stock
| Series: | 1200 | Angular Misalignment: | +/- 2.5 |
|---|---|---|---|
| Radial Clearance: | C3 | Dynamic Load Rating (kN): | 31 kN |
| Seal Type: | Unsealed | Cage Material: | Steel |
| Bore Type: | Straight | Rolling Element: | Ball |
| Static Load Rating (kN): | 12.4 kN | Material: | 52100 Bearing Steel |
| Misalignment: | Yes | Speed (Max) Grease (rpm): | 5, 300 rpm |
| Duplexing: | No | Sealed: | None |
| Full Complement/Caged: | Caged | Platform: | Self-Aligning Ball Bearings |
| Dynamic Load Rating (lb): | 6, 969 lb | Static Load Rating (lb): | 2, 788 lb |
| Speed (Max) Oil (rpm): | 6, 300 rpm | Mounting Method: | Shaft |
| UPC: | 637410093072 | Weight: | 2.49 LB |
| Packaged Length: | 4.72 Inches | Packaged Width: | 0.91 Inches |
| Packaged Height: | 4.72 Inches | Country of Origin: | China |
